SKU: BLA-ULTMSMTREM4

Blackmagic Design Ultimatte Smart Remote 4

R 56,170.60
Tax included Shipping calculated at checkout.

Blackmagic Design Ultimatte Smart Remote 4

The Blackmagic Design Ultimatte Smart Remote 4 is a dedicated hardware control panel designed to operate up to eight Ultimatte 12 real-time compositing processors simultaneously. While Ultimatte units can be controlled via software, the Smart Remote 4 provides the tactile, high-speed interface required by professional broadcast engineers for complex live virtual sets.

Core Functionality

  • Multi-Unit Control: A single remote can manage up to eight separate Ultimatte units via an Ethernet network. Users can quickly toggle between different cameras or virtual sets using the dedicated unit selection buttons.

  • Tactile Precision: Features eight high-resolution rotary encoders that allow for "blind" adjustments. This is critical when an operator needs to keep their eyes on the monitor while fine-tuning edge softness or color spill.

  • 10.1-inch Touchscreen: The large capacitive touchscreen displays the Blackmagic OS for Ultimatte, providing a visual menu system that is much faster than navigating via a mouse.

Key Features

  • One-Touch Keying: Includes a dedicated "File Clear" button that triggers Ultimatte's advanced auto-keying technology. It analyzes the scene and automatically sets the initial keying parameters based on the green or blue screen background.

  • Quick Load/Save: Five physical buttons allow for the instant saving and loading of complex setups into volatile RAM. This is vital for live productions that need to switch between different lighting setups or virtual environments instantly.

  • On-Air Indicators: Each unit ID button features LED status indicators: Green for "On Line" (connected) and Red for "On Air" (currently live on the program bus), preventing accidental adjustments to a live feed.

  • Customizable Menus: Users can build custom menus containing their most-used controls (e.g., specific matte controls or color correction tools) to streamline their specific workflow.

Technical Specifications

Feature Specification
Display 10.1-inch 1280 x 800 Color Touchscreen
Physical Controls 8 x Rotary Encoders, 5 x Preset Buttons, 8 x Unit Selectors
Connectivity 2 x 10/100 Mbps Ethernet (Control), 2 x USB (Updates), SVGA (External Monitor)
Mounting Adjustable desktop stand or 19-inch rack mount ears
Power 100-240V AC Internal Power Supply
OS Support Integrated Windows-based firmware / Blackmagic OS

Ultimatte Smart Remote 4 G2 (2026 Update)

Blackmagic recently released a G2 (Generation 2) version of this remote. While the core functionality remains the same, the G2 model offers several modern hardware updates:

  • USB-C Ports: Replaces the older USB-A ports for easier connection of modern peripherals.

  • HDMI Output: Replaces the legacy SVGA port, allowing the remote's interface to be mirrored to modern Full HD monitors.

  • Improved Ethernet: Upgraded to 10/100/1000 Mb/s for faster communication across complex enterprise networks.

  • Lower Price Point: Designed to be easier to manufacture, making high-end hardware control more accessible for mid-sized studios.

Operational Insight

In a professional virtual studio, the Smart Remote 4 is typically placed next to the technical director's monitoring stack. Because it controls the Ultimatte via Ethernet, it does not need to be physically near the processors, which are usually tucked away in a machine room. For high-stakes live TV, the physical knobs provide a safety net; if a lighting change occurs mid-broadcast, the operator can manually ride the "Clean Plate" or "Veil" levels instantly without fumbling with a computer mouse.

Blackmagic

Blackmagic Design Ultimatte Smart Remote 4

R 56,170.60

Blackmagic Design Ultimatte Smart Remote 4

The Blackmagic Design Ultimatte Smart Remote 4 is a dedicated hardware control panel designed to operate up to eight Ultimatte 12 real-time compositing processors simultaneously. While Ultimatte units can be controlled via software, the Smart Remote 4 provides the tactile, high-speed interface required by professional broadcast engineers for complex live virtual sets.

Core Functionality

  • Multi-Unit Control: A single remote can manage up to eight separate Ultimatte units via an Ethernet network. Users can quickly toggle between different cameras or virtual sets using the dedicated unit selection buttons.

  • Tactile Precision: Features eight high-resolution rotary encoders that allow for "blind" adjustments. This is critical when an operator needs to keep their eyes on the monitor while fine-tuning edge softness or color spill.

  • 10.1-inch Touchscreen: The large capacitive touchscreen displays the Blackmagic OS for Ultimatte, providing a visual menu system that is much faster than navigating via a mouse.

Key Features

  • One-Touch Keying: Includes a dedicated "File Clear" button that triggers Ultimatte's advanced auto-keying technology. It analyzes the scene and automatically sets the initial keying parameters based on the green or blue screen background.

  • Quick Load/Save: Five physical buttons allow for the instant saving and loading of complex setups into volatile RAM. This is vital for live productions that need to switch between different lighting setups or virtual environments instantly.

  • On-Air Indicators: Each unit ID button features LED status indicators: Green for "On Line" (connected) and Red for "On Air" (currently live on the program bus), preventing accidental adjustments to a live feed.

  • Customizable Menus: Users can build custom menus containing their most-used controls (e.g., specific matte controls or color correction tools) to streamline their specific workflow.

Technical Specifications

Feature Specification
Display 10.1-inch 1280 x 800 Color Touchscreen
Physical Controls 8 x Rotary Encoders, 5 x Preset Buttons, 8 x Unit Selectors
Connectivity 2 x 10/100 Mbps Ethernet (Control), 2 x USB (Updates), SVGA (External Monitor)
Mounting Adjustable desktop stand or 19-inch rack mount ears
Power 100-240V AC Internal Power Supply
OS Support Integrated Windows-based firmware / Blackmagic OS

Ultimatte Smart Remote 4 G2 (2026 Update)

Blackmagic recently released a G2 (Generation 2) version of this remote. While the core functionality remains the same, the G2 model offers several modern hardware updates:

  • USB-C Ports: Replaces the older USB-A ports for easier connection of modern peripherals.

  • HDMI Output: Replaces the legacy SVGA port, allowing the remote's interface to be mirrored to modern Full HD monitors.

  • Improved Ethernet: Upgraded to 10/100/1000 Mb/s for faster communication across complex enterprise networks.

  • Lower Price Point: Designed to be easier to manufacture, making high-end hardware control more accessible for mid-sized studios.

Operational Insight

In a professional virtual studio, the Smart Remote 4 is typically placed next to the technical director's monitoring stack. Because it controls the Ultimatte via Ethernet, it does not need to be physically near the processors, which are usually tucked away in a machine room. For high-stakes live TV, the physical knobs provide a safety net; if a lighting change occurs mid-broadcast, the operator can manually ride the "Clean Plate" or "Veil" levels instantly without fumbling with a computer mouse.
